Model

TEM-38-150-A

TEM-38-225-A

TEM-38-300-A

Cathode material

Lithium iron phosphate

Cell capacity

75Ah

75Ah

150Ah

Group mode

2P12S

3P12S

2P12S

Rated Voltage

38.4V

Rated capacity

150Ah

225Ah

300Ah

Rated power

5.76kWh

8.64kWh

11.52kWh

Voltage range

34.8-42V(2.9-3.5V)

Rated charge and discharge power

5.76kW

4.32kW

5.76kW

Rated charge and discharge current

150A

112.5A

150A

Maximum charging and discharging current

180A

165A

Charge and discharge efficiency2

≥95%

Operating Temperature

Charge:0℃~55℃;discharge:-20℃~55℃

Optimal storage temperature2

15℃~35℃

Relative humidity

0~85%RH,non-condensing

0~90%RH,non-condensing

0~90%RH,non-condensing

Maximum allowable altitude

≤4000m

Cycle life

≥6000 cycles (0.5C,25℃,90%DOD g 80%EOL)

Self power consumption/month

≤3%

Cooling method

Air cooling

(BMS+FAN)Power Consumption(BMS+FAN)

≈12W

Communication mode

CAN2.0

IP Class

IP20

Overall dimensions (without lugs)

360mm×573mm×242mm

478mm×573mm×242mm

420mm×670mm×242mm

Weight

66±1kg

87±1kg

93±0.5kg

Cathode material

Lithium iron phosphate

Cell capacity

280Ah

150Ah

280Ah

Group mode

1P16S

1P24S

1P52S

Rated Voltage

51.2V

76.8V

166.4V

Rated capacity

280Ah

150Ah

280Ah

Rated power1

14.336kWh

11.52kWh

46.59kWh

Voltage range

46.4-56V(2.9-3.5V)

69.6-84V (2.9-3.5V)

145.6-189.8V(2.8-3.65V)

Rated charge and discharge power

7.168kW

11.52kW

23.296kW

Rated charge and discharge current

150A

140A

140A

Maximum charging and discharging current

165A

150A

280A

Charge and discharge efficiency2

≥95%

Operating Temperature

Charge:0℃~55℃;discharge:-20℃~55℃

Optimal storage temperature2

15℃~35℃

Relative humidity

0~90%RH,non-condensing

Maximum allowable altitude

≤4000m

Cycle life

≥6000 cycles (0.5C,25℃,90%DOD(cycles)80%EOL)

Selfpower consumption/month

≤3%

Cooling method

Air cooling

Liquid cooling

(BMS+FAN)Power Consumption (BMS+FAN

≈12W

≈3W

Communication mode

CAN2.0

IP Class

IP20

IP67

Overall dimensions (without lugs)

420mm×790mm×242mm

478mm×749mm×242mm

810mm×1200mm×240mm

Weight

115±1kg

98±0.5kg

≈350kg
