Item

HP10132E

7KW/32A

HP10316E

11KW/16A

HP10332E

22KW/32A

Input

Power Supply

1P+N+PE

1P+2P+3P+N+PE

1P+2P+3P+N+PE

Rated Voltage

AC220V±15%

AC 380V±15%

AC380V±15%

Rated current

32A

16A

32A

Output

Output Voltage

AC220V±15%

AC380V±15%

AC380V±15%

Maximum Current

32A (6~32A adjustable)

16A (0~16A adjustable)

22KW(MAX)

32A (6~32A adjustable)

Rated Power

7KW(MAX)

11KW(MAX)

22KW(MAX)

Dynamic load balancing(extra device)

O

O

O

User

interface

Tethered/Untethered

Tethered-Type2.5M cable

Tethered-Type25M cable

Tethered-Type25M cable

Material

PC+ABS

Colour

White front+grey back

Indicator

4 indicators

Display

X

X

X

Ethernet(RJ45)

X

X

X

Wifi or Bluetooth

2.4G wifi

OCPP1.6 Interface

O

O

O

WE E-Charge App

O

O

O

Start Mode

RFID/APP

Plug in and charge

O

O

O

Safety

Ingress Protection

IP65,IK10

Residual current protection

Type B RCMU

Over load protection

√

√

√

Over/Under voltage protection

√

√

√

Short circuit protection

√

√

√

Earth Leakage Protection

√

√

√

Ground Protection

√

√

√

Surge protection

√

√

√

Over temperature

√

√

√

PEN protection

O

O

√

Certification

CE,RoHS,Reach

Environment

Installation(mounting pole optional)

Wall mounted

Work Temperature

-30~55℃

-30~55℃

-30~55℃ 3%~95%

Work Humidity

3%~95%

3%~95%

3%~95%

Work Altitude

<2000m

Package

Production Dimension(H*W*D)mm

310*220*95

310*220*95

310*220*95

Package Dimension(L*W*H)mm

400*350*260

400*350*260

400*350*260
